Step 2
å
Fasten the ENDS (A and B) to the TOP (E). Tighten four
HIDDEN CAMS.
414356 www.sauder.com/servicesPage 6
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
A
B
E
Notched edge
Notched edge
Long Finished edge
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Surface
with holes
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
