Step 16
419119 www.sauder.com/servicesPage 20
å
Before fastening the DOOR to your unit, be sure the
mounting screw is against the stops as shown in the right
diagram. If it isn't, loosen the mounting screw to slide it
against the stops. Then tighten the mounting screw.
å
Fasten a DOOR (L) to the LEFT END (B) as shown in
the lower diagram. Use the screws in the HINGES. You
should start each SCREW a few turns before completely
tightening any of them.
å
Fasten a PULL (53K) to the DOOR (L). Use two SILVER
3/8" MACHINE SCREWS (97S).
å
Peel the FELT DISC from the FELT DISC CARD (1M) and
stick them on the corner of the DOOR (L) where they
come in contact with the MOLDING (X) when closed.
å
Repeat this step for the other DOOR (L).
å
See the next step for DOOR adjustments.
Mounting
screw
Stop
Hinge
SILVER 3/8" MACHINE SCREW
(4 used in this step)
97S
L
B
X
53K
1M
1M
