Step 5
419200www.sauder.com/services
Page 9
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
å
Fasten the TOP/BOTTOMS (C) and SHELF (D) to the ENDS (A
and B). Tighten twelve TWIST-LOCK® FASTENERS.
How to use the SAUDER TWIST-LOCK
®
FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoining part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoining part while locking
the FASTENER.
2. Tighten the FASTENER with a Phillips screwdriver as tight
as possible.
Dowel end
D
J
C
C
A
B
H
H
Surface with
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
Surface without
TWIST-LOCK®
FASTENERS
Edge with
ANGLE BRACKETS
Edge with
ANGLE BRACKETS
