Sauder 419954 - Step 13; Using Sauder Twist-Lock Fasteners

å
Fasten the BOTTOMS (C) to the ENDS (A and B). Tihten
four TWIST-LOCK® FASTENERS.
å
Slide the BOTTOM MOLDINGS* (J) onto the notched
edes of the BOTTOMS (C).
å
*U.S. Patent No. 5,499,886
Step 13
419954www.sauder.com/services
Pae 17
Surface with
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
J
C
J
C
How to use the SAUDER TWIST-LOCK
®
FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoinin part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoinin part while lockin
the FASTENER.
2. Tihten the FASTENER with a Phillips screwdriver as tiht
as possible.
Dowel end
Slide the BOTTOM MOLDING (J)
onto the notched ede.
Notched ede
Notched ede
These surfaces
should be even.
Short ede
B
A
Short ede
H
P
