Turn the UPRIGHTS (D and E) over.
å
Fasten the EXTENSION BLOCKS (T) to the UPRIGHTS (D and E). Use four BLACK 1-1/4" FLAT HEAD SCREWS (7S).
å
Fasten the remainin two NARROW EXTENSION RAILS (AA) to the UPRIGHTS (D and E). Use four GOLD 5/16" FLAT
HEAD SCREWS (3S) throuh holes #1 and #3.
å
NOTE: For each NARROW EXTENSION RAIL, turn a SCREW into the hole shown in the enlared diaram. Then, slide the
inner cartride of the NARROW EXTENSION RAIL in to fi nd the other hole that lines up with the hole in the ENDS and
UPRIGHTS. Turn a SCREW into this hole.
GOLD 5/16" FLAT HEAD SCREW
(4 used for the RAILS)
3S
E
D
AA
AA
Open end
Open end
BLACK 1-1/4" FLAT HEAD SCREW
(4 used for the EXTENSION BLOCKS)
7S
T
T
Surface without
TWIST-LOCK®
FASTENERS
Surface without
TWIST-LOCK®
FASTENERS
The lare hole
must be here.
H
P
1
3
2
4
1
3
2
4
Surface with
more holes
Unfi nished
strip
