Sauder 419954 - Step 11

Step 11
419954www.sauder.com/services
Pae 15
Push the black lever in and pull the SLIDE from the RAIL.
å
Separate the NARROW EXTENSION SLIDES (BB) from the NARROW EXTENSION RAILS (AA) as shown in the upper
diaram below. Be prepared, the parts are reasy.
å
Fasten eiht NARROW EXTENSION RAILS (AA) to the ENDS (A and B) and UPRIGHTS (D and E). Use sixteen GOLD 5/16"
FLAT HEAD SCREWS (3S) throuh holes #1 and #3.
å
NOTE: For each NARROW EXTENSION RAIL, turn a SCREW into the hole shown in the enlared diaram. Then, slide the
inner cartride of the NARROW EXTENSION RAIL in to fi nd the other hole that lines up with the hole in the ENDS and
UPRIGHTS. Turn a SCREW into this hole.
å
NOTE: The NARROW EXTENSION SLIDES will be used later for the SMALL DRAWERS and PENCIL DRAWER.
GOLD 5/16" FLAT HEAD SCREW
(16 used in this step)
3S
A
B
E
D
AA
AA
AABB
AA
AA
AA
AA
AA
AA
Open end
Open end
Open end
Open end
1
3
2
4
1
3
2
4
1
3
2
4
1
3
2
4
1
3
2
4
1
3
2
4
1
3
2
4
1
3
2
4
