Hardware Identifi cation
å Screws are shown actual size. You may receive extra hardware with your unit.
(EXTENSION SET SHOWN SEPARATED)
WIDE EXTENSION
RAIL - 4
Y
WIDE EXTENSION
SLIDE - 4
Z
(EXTENSION SET SHOWN SEPARATED)
AA
NARROW EXTENSION
RAIL - 10
BB
NARROW EXTENSION
SLIDE - 10
FILE ROD - 4
8B
FILE GLIDE - 4
15B
10A
SLIDE CAM - 12
HIDDEN
CAM - 34
1F
CAM
SCREW - 34
8F 12F
TWIST-LOCK
®
FASTENER - 22
WOOD
DOWEL - 16
15F
GLUE - 1
54M
GROMMET CAP - 2
1P
GROMMET - 2
10P
3S
GOLD 5/16" FLAT HEAD SCREW - 48 BLACK 1-1/4" FLAT HEAD SCREW - 4
7S
BLACK 7/8" LARGE HEAD SCREW - 3
17S
BLACK 1-1/8" MACHINE SCREW - 6
21S
30S
BLACK 1-9/16" FLAT HEAD SCREW - 28 BLACK 9/16" FLAT HEAD SCREW - 18
32S
BLACK 7/8" MACHINE SCREW - 2
37S
BLACK 1-15/16" FLAT HEAD SCREW - 10
113S
KNOB SET - 8
136K
