Carefully turn your unit over onto its BACK.
å
Place the SMALL DOOR assembly next to the SMALL
END (A2). Place packing material, books or magazines
underneath the SMALL DOOR assembly for support while
you fasten the HINGES (1H) to the SMALL END.
å
Fasten the HINGES (1H) to the SMALL END (A2). Use
eight BLACK 9/16" LARGE HEAD SCREWS (1S).
å
Push the MAGNETIC CATCHES (3I) into the holes in the
top and bottom corners of the UPRIGHT (D2).
Step 11
BLACK 9/16" LARGE HEAD SCREW
(8 used for the HINGES)
1S
3I
3I
Place packing material, books,
or magazines underneath the
SMALL DOOR for support.
A2
D2
422427www.sauder.com/services
Page 17
LARGE DOOR ON LEFT
