Sauder 429430 - Assembly Tools; Product Identification; Part Identification Guide

Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Assembly Tools RequiredTable of Contents
2-3
4
5-18
19-21
22-24
25-26
27
A RIGHT END (1)
B LEFT END (1)
C UPRIGHT (1)
D TOP (1)
E BOTTOM (1)
F SHELF (1)
H RIGHT DOOR (1)
J ADJUSTABLE SHELF (4)
K VALANCE (2)
L SKIRT (1)
M BACK (1)
N LEFT DOOR (1)
å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
Part Identification
Tape Measure
Page 2 www.sauder.com 429430 / 168-0094-8
Electric drill with 1/8" or 3/8" bit
(ONLY in indicated step)
Pencil
