Step 1
å
Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å
Fasten five ANGLE BRACKETS (1) to the SKIRT (L). Use
five LARGE 1/2" PAN HEAD SCREWS (19).
å
NOTE: Be sure the edges of the ANGLE BRACKETS are
even with the edges of the SKIRT.
å
Fasten the BOTTOM BRACKET (9) to the BOTTOM (E).
Use two 1/2" PAN HEAD SCREWS (18).
1
1/2" PAN HEAD SCREW
(2 used in this step)
18
L
1
1
E
9
The molding on the other surface
of the BOTTOM should be here.
LARGE 1/2" PAN HEAD SCREW
(5 used for the ANGLE BRACKETS)
19
Look for this icon. It means a video assembly tip is
available at www.sauder.com/service/tips
Find the numbered video or scan the QR code.
0
Page 5www.sauder.com429430 / 168-0094-8
