Screws are shown actual size. You may receive extra hardware with your unit.
PART IDENTIFICATION: While not all parts are labeled, some of the parts will have a label or an inked
letter on the edge to help distinguish similar parts from each other. Use this PART IDENTIFICATION to help
identify similar parts.
G TOP 1
H LONG BRACE 2
I SHORT BRACE 2
J LEG BRACE 2
K RIGHT FRONT/LEFT REAR LEG 2
L LEFT FRONT/RIGHT REAR LEG 2
G
H
H
I
I
J
J
K
K
L
L
HIDDEN CONNECTOR -4
M
SCREW COVER - 12
O
METAL PIN - 8
N
BLACK 1-1/8" PAN HEAD SCREW - 8
Q
CONNECTOR SCREW - 4
R
BLACK 1-7/8" FLAT HEAD SCREW - 12
P
Page 3
www.sauder.com/services414289
To Next Page
