Table of Contents Assembly Tools Required
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Hammer
Not actual size
A RIGHT END (1)
B UPPER LEFT END (1)
B59 LARGE DRAWER BOTTOM (1)
C LOWER LEFT END (1)
D UPRIGHT (1)
D36 RIGHT DRAWER SIDE (1)
D37 LEFT DRAWER SIDE (1)
D48 FILE RIGHT DRAWER SIDE (1)
D49 FILE LEFT DRAWER SIDE (1)
D77 DRAWER BACK (1)
D78 FILE DRAWER BACK (1)
D113 PENCIL DRAWER SIDE (2)
D574
PENCIL DRAWER BOX FRONT (2)
D716 SMALL DRAWER BOTTOM (2)
E2 TOP (1)
F BOTTOM (1)
G MODESTY PANEL (1)
H BACK (1)
I BRACE (1)
J DRAWER FRONT (1)
M71
DRAWER BRACE (1)
(Hidden part using recycled
material. Color may vary.)
M75 END MOLDING (1)
N FILE DRAWER FRONT (1)
R3 PENCIL DRAWER FRONT (1)
U RIGHT FRONT LEG (1)
V LEFT FRONT LEG (1)
W RIGHT REAR LEG (1)
X LEFT REAR LEG (1)
Y CENTER LEG (1)
Z EXTENSION BLOCK (1)
2-3
4-5
6-34
35-39
40-44
45-46
47
å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts.
Now you know
our ABCs.
