Sauder Carson Forge Armoire - Hardware Identification

Hardware Identifi cation
å Screws are shown actual size. You may receive extra hardware with your unit.
5L
WARNING LABEL - 1
(Refer to step 18 for proper
location and application)
WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Place heaviest items in the lowest drawers.
• Unless specifi cally desined to accommodate, do not
set TVs or other heavy objects on top of this product.
• Never allow children to climb or han on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
• If equipped with a drawer interlock system, do not
defeat or remove it.
Use of tip-over restraints may only reduce, but not
eliminate, the risk of tip-over.
This is a permanent label. Do not attempt to remove!
04/10 332296
31G
CORNER BRACKET - 2
PULL - 1
53K
FOOT CAP - 2
10E
SAFETY BRACKET - 1
1G
TIE PLATE - 2
3G
7A
ROD HANGER - 2
SUPPORT PIN - 8
5R
10A
SLIDE CAM - 2
12E
TACK GLIDE - 2
CAM SCREW - 9
8F
WOOD DOWEL - 6
15F
NAIL - 47
1N
HIDDEN CAM - 9
1F
KNOB - 2
52K
GLUE - 1
54M
LARGE RUBBER
SLEEVE - 2
59G
13H
HINGE - 6
35AA
UNIVERSAL CABINET RAIL - 2
35AC
DRAWER RIGHT - 1
35AD
DRAWER LEFT - 1
415107 www.sauder.com/servicesPae 4
7F
TWIST-LOCK
®
FASTENER - 12
METAL BRACKET - 6
4G
