Sauder Carson Forge Armoire - Step 3: Cam Screw and Hidden Cam Installation

å
Turn nine CAM SCREWS (8F) into the FEET (I and J),
DRAWER FRONT (L), SHELF MOLDING (M), and
BOTTOM MOLDING (N).
å
Push nine HIDDEN CAMS (1F) into the BOTTOM (D),
SHELF (E), SKIRT (G), and DRAWER BRACE (M65).
Step 3
I
J
L
M
N
8F
Arrow
Arrow
1F
The arrow in the HIDDEN
CAM must point toward the
hole in the ede of the board.
Hole
1F
Arrow
D
E
G
M65
