This unit can be hung vertically as shown in the upper diagram or
horizontally as shown in the lower diagram.
å
Fasten two MIRROR HANGERS (52M) to the TOP/BOTTOM RAIL (B) as
shown in the upper diagram to hang the MIRROR vertically. Use four BLACK
9/16" LARGE HEAD SCREWS (1S).
å
Fasten two MIRROR HANGERS (52M) to the TOP/BOTTOM RAILS (B)
as shown in the lower diagram to hang the MIRROR horizontally. Use four
BLACK 9/16" LARGE HEAD SCREWS (1S).
Step 6
415556www.sauder.com/services
Page 9
BLACK 9/16" LARGE HEAD SCREW
(4 used in this step)
1S
B
B
B
52M
Mirror hanging vertically
Mirror hanging horizontally
52M
