Step 4
å
Fasten the LEFT END (B) to the LEFT MOLDING (N).
Tighten two HIDDEN CAMS.
å
Fasten the SHELF (E) to the LEFT END (B). Tighten two
HIDDEN CAMS.
400742 www.sauder.com/servicesPage 8
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Finished edge
Curved edge
D
E
B
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
L
M
N
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
