Sauder Harbor View 403793 - Step 22: Fasten Door and Knob

Step 22
403793www.sauder.com/services
Pae 27
å
Before fastenin the DOOR to your unit, be sure the
mountin screw is aainst the stops as shown in the riht
diaram. If it isn't, loosen the mountin screw to slide it
aainst the stops. Then tihten the mountin screw.
å
Fasten the DOOR (M) to the LEFT END (B) as shown in
the lower diaram. Use the screws in the HINGES. You
should start each SCREW a few turns before completely
tihtenin any of them.
å
Fasten a KNOB (WW) to the DOOR (M). Use a BLACK
1-1/8" PAN HEAD SCREW (HHH).
å
Peel the FELT DISC from the FELT DISC CARD (FFF).
Stick a FELT DISC on the DOOR where it comes in
contact with the RIGHT END (A).
å
See the next step for DOOR adjustments.
Mountin
screw
Stop
Hine
M
B
A
BLACK 1-1/8" PAN HEAD SCREW
(1 used for the KNOB)
HHH
FFF
WW
FFF
