Fasten the DRAWER ENDS (C and D) to the BRACES (L).
Tighten four HIDDEN CAMS.
å
NOTE: Be sure the METAL PINS in the ENDS insert into
the holes in the BRACES.
Step 9
C
D
L
L
Surface with
HIDDEN CAMS
Surface
with ANGLE
BRACKETS
Surface without
HIDDEN CAMS
Surface with
HIDDEN
CAMS
Edge with CAM DOWELS
These holes must be here.
The ANGLE
BRACKETS
must be here.
