Step
å
Fasten the LEFT MOLDING (BB) to the TOP (G3). Use
three BLACK 1-1/8" PAN HEAD SCREWS (9S).
å
Fasten the UPRIGHTS (E and F) to the TOP (G3). Tighten
two HIDDEN CAMS.
Step 20
Arrow
Minimum
190 degrees
Maximum
210 degrees
G3
E
F
BB
Surface with
HIDDEN CAM
Surface with
HIDDEN CAM
BLACK 1-1/8" PAN HEAD SCREW
(3 used in this step)
9S
Flat end
417586 www.sauder.com/servicePage 26
DOOR ON LEFT AND
DRAWERS ON RIGHT
