Step
å
Use a drill and a 1/8" drill bit to fi nish drilling the two holes
shown in the DOOR RIGHT END (A).
å
Fasten the MODESTY PANEL (I) to the LEFT UPRIGHT (F).
Use two BLACK 1-1/8" PAN HEAD SCREWS (9S).
å
Fasten the MODESTY PANEL (I) to the DOOR RIGHT END (A).
Use two BLACK 1-7/8" FLAT HEAD SCREWS (2S).
Step 21
F
I
A
BLACK 1-1/8" PAN HEAD SCREW
(2 used in this step)
9S
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
2S
Use a 1/8" drill bit to fi nish drilling these holes completely through.
Cut-out
417586www.sauder.com/service
Page 27
DOOR ON LEFT AND
DRAWERS ON RIGHT
