Step 44
å
Push a GROMMET (10P) into the large hole in the TOP (G3).
Then insert the GROMMET CAP (1P) into the GROMMET.
å
Push four RUBBER SLEEVES (2R) over four METAL PINS (1R).
Insert the METAL PINS into the hole locations of your choice in
the DOOR ENDS (A and B). Set the ADJUSTABLE SHELF (P)
onto the METAL PINS.
å
To insert the drawers into your unit, tip the front of the drawer
down and drop the rollers on the drawer behind the rollers on
the unit. Lift the front of the drawer up and slide it into the unit.
Repeat this step to insert the KEYBOARD SHELF.
1P
10P
G3
60 lbs.
25 lbs.
40 lbs.
30 lbs.
10 lbs.
each
50 lbs.
A
B
25 lbs.
P
(4 used)
1R
2R
417586www.sauder.com/service
Page 53
