Carefully turn your unit over onto its front edges. Unfold
the LARGE BACK (H) and lay the BACKS (H and I) over
your unit. Align notches in BACKS (I) to notches in
LARGE BACK (H).
å
Make equal margins along all edges of the BACKS (H
and I). Push on opposite corners of your unit if needed to
make it “square”.
å
Fasten the BACKS (H and I) to your unit using the NAILS (1N)
and six BROWN 7/16” LARGE HEAD SCREWS (6S) through
the BACK (H) and into the SMALL BACKS (J).
å
NOTE: Perforations have been provided for access
through the BACK. Carefully cut out the holes needed.
Step 11
417587www.sauder.com/services
Page 15
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Unfi nished surface
NAIL
(46 used in this step)
1N
Unfi nished surface
Unfi nished surface
J
J
H
I
I
BROWN 7/16" LARGE HEAD SCREW
(6 used in this step)
6S
