Insert ten CAMS (P1) into the MODESTY PANEL (B),
ENDS (C and F), and UPRIGHTS (D and E).
å
NOTE: Be sure the arrows in the CAMS are pointing up.
å
Fasten the TOP (A) to the MODESTY PANEL (B), ENDS (C
and F), and UPRIGHTS (D and E). Tighten the CAMS onto
the PINS.
å
NOTE: Be sure the DOWELS insert into the TOP.
Step 12
3
21
Arrow
P1
P1
P1
A
B
C
D
E
F
Page 16 www.sauder.com 402159
P1
The arrow must
point toward the
edge of the board
To Next Page
