Page 20 www.sauder.com/service 423720
å
Fasten the LEFT DRAWER SLIDE (6) to the SMALL LEFT
DRAWER SIDE (UL) and the RIGHT DRAWER SLIDE (5)
to the SMALL RIGHT DRAWER SIDE (UR). Use six BLACK
1/2" FLAT HEAD SCREWS (16).
å
NOTE: The SLIDES will wrap around the long edge of the
SMALL DRAWER SIDES.
Step 16
Roller end
Roller end
BLACK 1/2" FLAT HEAD SCREW
(6 used in this step)
16
UL
UR
5
6
