First, fi ll the hole in the LEFT BOTTOM MOLDING (M) 1/4 to 1/2 full
with GLUE. Then, insert the WOOD DOWEL (15F) into this hole. Wipe
away the excess GLUE.
å
Now, fi ll the hole in the SHORT BRACE (P) 1/4 to 1/2 full with GLUE.
å
Fasten the SHORT BRACE (P) to the LEFT BOTTOM MOLDING (M).
Use one BLACK 2-3/8" FLAT HEAD BOLT (103S).
å
NOTE: Be sure the WOOD DOWEL in the LEFT BOTTOM MOLDING
inserts into the SHORT BRACE. Wipe away the excess GLUE.
å
NOTE: The BOLT will thread into the DOWEL in the SHORT BRACE.
Step 12
425014www.sauder.com/service
Page 17
M
P
Fill the holes 1/4 to 1/2 full with GLUE.
Inspect the parts thoroughly before
assembling. Disassembly of glued
parts is extremely di cult.
Caution
!
54M
15F
103S
BLACK 2-3/8" FLAT HEAD BOLT
(1 used for the SHORT BRACE)
Surface with slotted dowels
