Step 13
425014 www.sauder.com/servicePage 18
P
E
K
å
First, fi ll the hole in the RIGHT BACK (K) 1/4 to 1/2 full with GLUE.
Then, insert the WOOD DOWEL (15F) into this hole. Wipe away the
excess GLUE.
å
Now, fi ll the hole in the SHORT BRACE (P) 1/4 to 1/2 full with GLUE.
å
Next, fasten the RIGHT BACK (K) to the LONG MODESTY PANEL (E).
Tighten two HIDDEN CAMS.
å
NOTE: Be sure the WOOD DOWEL in the RIGHT BACK (K) inserts
into the SHORT BRACE (P). Wipe away the excess GLUE.
å
Fasten the RIGHT BACK (K) to the SHORT BRACE (P). Use one
BLACK 2-3/8" FLAT HEAD BOLT (103S).
103S
BLACK 2-3/8" FLAT HEAD BOLT
(1 used for the SHORT BRACE)
Fill the holes 1/4 to 1/2 full with GLUE.
Inspect the parts thoroughly before
assembling. Disassembly of glued
parts is extremely di cult.
Caution
!
54M
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Surface with
more holes
