Step 14
425014www.sauder.com/service
Page 19
å
First, fi ll the holes in the BRACE (N) 1/4 to 1/2 full with
GLUE (54M). Then, insert the WOOD DOWELS (15F)
into the holes. Wipe away the excess GLUE.
å
Now, fi ll the hole in the LEFT END (B) 1/4 to 1/2 full
with GLUE.
å
Fasten the BRACE (N) to the LEFT END (B). Tighten
one HIDDEN CAM.
å
NOTE: Be sure the WOOD DOWEL in the BRACE
inserts into the LEFT END. Wipe away the excess GLUE.
Arrow
Minimum
190 degrees
Maximum
210 degrees
N
Fill the holes 1/4 to 1/2 full with GLUE.
Inspect the parts thoroughly before
assembling. Disassembly of glued
parts is extremely di cult.
Caution
!
54M
Surface with
HIDDEN CAMS
15F
Finished edge
B
