Sauder Summit Station 425014 - Page 20

å
Slide the FRONT/BACK MOLDINGS* (J) onto the
notched edges of the BOTTOM (D).
å
Fasten the BOTTOM (D) to the LEFT BOTTOM
MOLDING (M). Tighten two HIDDEN CAMS.
å
*U.S. Patent No. 5,499,886
Step 15
425014 www.sauder.com/servicePage 20
Notched edge
The groove
is closer to
this edge.
The groove
is closer to
this edge.
Notched edge
These surfaces
should be even.
D
J
J
D
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
M
