Sauder Summit Station 425014 - Page 24

Step 19
425014 www.sauder.com/servicePage 24
å
First, fi ll the hole in the end of the LEFT BRACE (O) 1/4 to 1/2 full
with GLUE (54M). Then, insert the WOOD DOWEL (15F) into the
hole. Wipe away the excess GLUE.
å
Now, fi ll the hole in the LONG BRACE (Q) 1/4 to 1/2 full with GLUE.
å
Fasten the LONG BRACE (Q) to the LEFT BRACE (O). Use one
BLACK 2-3/8" FLAT HEAD BOLT (103S).
å
NOTE: Be sure the WOOD DOWEL in the LEFT BRACE inserts into
the LONG BRACE. Wipe away the excess GLUE.
Q
Fill the holes 1/4 to 1/2 full with GLUE.
Inspect the parts thoroughly before
assembling. Disassembly of glued
parts is extremely di cult.
Caution
!
54M
103S
BLACK 2-3/8" FLAT HEAD BOLT
(1 used for the LONG BRACE)
Surface with slotted dowels
15F
O
