Table of Contents Assembly Tools Required
2-3
4
5-22
23-25
26-28
29-30
31
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
414417 www.sauder.com/servicesPage 2
Part Identifi cation
å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts.
A LOWER END (1)
B HUTCH END (2)
C UPRIGHT (1)
D CENTER UPRIGHT (1)
E HUTCH UPRIGHT (2)
F2 LOWER TOP (1)
G HUTCH TOP (1)
H2 TOP (1)
I HUTCH BOTTOM (1)
J SHELF (1)
K BOTTOM (1)
L DESK BACK (1)
M LOWER BACK (1)
N HUTCH BACK (1)
O FLIP DOWN DOOR (1)
P DRAWER FRONT (1)
Q DRAWER BACK (1)
R RIGHT DRAWER SIDE (1)
S LEFT DRAWER SIDE (1)
T DRAWER BOTTOM (1)
U DIVIDER (1)
V DESK FRAME (2)
W RETURN FRAME (2)
X UPPER MOLDING (1)
Y LOWER MOLDING (1)
