Part No. 000841, 12-m01-2018 Eclipse (Micro-6) Owner’s Manual
1. SPECIFICATIONS
Eclipse Specifications
Load capacity 750 lb (341 kg), 950 lb (432 kg), 1000 lb (454 kg)
Rated speed 40 ft/min (0.2 m/s) nominal
Maximum travel 50 ft (15.24 m); 60 ft (18.3 m) available where code is not applicable
Maximum # of stops 6 stops
Daily cycle
Normal: 40
Heavy: 80
Excessive: 150
Maximum starts in 1 hour on standard installation: 20
Power supply (circuit
supplied by others)
North America: 230 volt, single phase, 60 Hz, 20 amps
International: 220 volt, single phase, 50 Hz
Lighting supply
(circuit supplied by
others)
120 volt, 60 Hz, 15 amps
Drive system
Automatic 2 HP geared motor roller chain variable frequency drive,
complete with counterweight
Operating
temperature
-10° C to +40° C (14° F to 104° F)
Cab sizes
Types 1, 2, 3, 4 and 5:
• 36” x 48” x 80” (914 mm x 1219 mm x 2032 mm)
• 36” x 54” x 80” (914 mm x 1372 mm x 2032 mm)
• 36” x 60” x 80” (914 mm x 1524 mm x 2032 mm)
• 40” x 54” x 80” (1016 mm x 1372 mm x 2032 mm)
Control system Micro-6 controller with diagnostics
Pit depth required 6” (152 mm); 11” (279 mm) minimum with buffer springs
Minimum overhead
clearance
96” (2438 mm) for standard 80” cab, 114” (2896 mm) for 96” cab
Cab panel finish
Solid melamine or MDF panels (standard)
Unfinished veneer panels, finished recessed veneer panels, solid
hardwood raised panels (optional)
Control panel finish
Clear or bronze anodized aluminum (standard)
Stainless steel or brass (optional)
Hall station finish
Clear or bronze anodized aluminum (standard)
Stainless steel or brass (optional)
Standard features
Automatic on/off cab lighting
Recessed gate pocket
Digital display in cab operating panel
Clear or bronze anodized aluminum cab entrance trim and handrail
Date plates, capacity tags
Modular rail sections
Unfinished plywood sub-floor
White ceiling with four LED lights
