Part No. 001022, 08-m05-2020 K2 Stairlift Owner’s Manual
Emergency Manual Operation
If necessary, you can operate the lift manually using the manual operation tool
(handwheel) as described here.
1 Turn OFF the main power switch.
2 Remove the access cover on the lower side of the unit. To do this, place a flat
blade screwdriver carefully under the corner of the cover and gently pry out
to pop the cover off.
Figure 5
3 Fit the shaft of the manual operation tool (shown above) onto the motor
shaft which is located below the battery tray in the carriage (circled below).
Figure 6
Batteries not
installed in
this view
