Part No. 001022, 08-m05-2020 K2 Stairlift Owner’s Manual
1. DESCRIPTION
Figure 1 shows the exterior components of the K2 Stairlift (with L-seat).
Figure 1
Backrest
Adjustable armrests
Flip-up seat
(swivel out, up/down
adjustable)
UP/DOWN
toggle switch
Retractable
seat belt (for
Folding
Carriage
footrest
Seat swivel
handle
Key switch
Diagnostic
LEDs (behind
folded footrest)
ON/OFF
switch
indoor unit;
non-retractable
for outdoor unit)
