Multilift (B613) Planning Guide Part No. 000790, 01-m06-2011
Specifications
Multilift specifications
Applications Residential (indoor/outdoor)
Load capacity 750 lb (340 kg)
Maximum travel distance 48” (1219 mm); optionally 72” (1829 mm)
Levels serviced 2
Travel speed 8 ft/min (0.04 m/s)
Cab types/sizes
Type 2, 3 or 4 with platform gate (unenclosed hoistway):
• 36” x 48” (914 mm x 1219 mm)
• 36” x 54” (914 mm x 1371 mm)
• 36” x 60” (914 mm x 1524 mm)
Side guard panels 42
1/8” (1070 mm) side guard panels on platform
Cab access
Front/rear access - standard (platform Type 2)
90 degree access - optional (platform Type 3 and 4)
Power supply 120 VAC, 20 A, 60 Hz, single phase
Drive system
Acme screw and back-up nut
Standard: 1/2 hp (0.37 Kw) motor, 12-volt battery model
Optional: 1 hp (0.74 Kw) motor, 110 VAC model
Control system Electronic-free relay logic controller
Finish Beige electrostatic powder coat paint on all steel surfaces and vacuum-formed plastics
Features
Call/send stations at landings
Continuous-pressure type buttons
Operating control buttons on platform
Emergency manual lowering/raising device
Low-voltage controls
Underpan sensors
Non-skid platform surface
Automatic access ramp (24”); field reversible to suit installation needs
Emergency stop button
