Savoy Timber - Balustrade Installation Guide; Balustrade Components

1
5
6
7
8
9
10
2
1600 mm
Post
Infill
Post Cap
Post Skirt
Rail Supports
Rail Connector
Top & Bottom
Rail
Spindle
100 mm
Stainless Steel Screw
Galvanised Post Support
1480 mm
BALUSTRADE COMPONENTS
120 X 120mm
Post Cap
120 X 120mm
Post
31 X 21mm
Post Infill
100 x 66 x 1480mm
Top+Bottom Rail
60 x 44mm
Spindle
100mm x 60mm x 44mm
Rail Supports
120mm x 120mm
Post Skirt
75mm x 33mm
Rail Connector
58 x 58 x 500mm
Galvanised Post
Support
4 x 35mm Stainless
Steel Screw
1 4 5
3
6 7 8
9
10
2
BALUSTRADE
INSTALLATION GUIDE
4
3
