ASSEMBLINGYOURNEWHEATER
TopGrill
SomeheatersintheSaxon
range have a pair of top
grills.Theseareshapedto
fitneatlyintocutoutsontop
ofthefirebox.
BafflePlate
ThebaffleplateforyourSaxonheaterconsists
of a steel frame and a Skamolex baffle. To
placethebaffleintotheheater,firstplacethe
Skamolex baffle into the steel frame then
positionintothefirebox.
Youmayneedtoanglethebaffleuponone
sidetogetitthroughthedoor.Youshouldthen
liftthebaffleoveronebracket,pushituptothe
topofthefirebox,andthenliftitovertheother
bracket.
3
LiftingHandles-Mahoganyonly
Theliftinghandlesmustbeusedwhenmoving
the Saxon Mahogany heater. They can be
foundinsidethefirebox.
Thehandlesshouldslideintotubesfoundon
theleftandrightsidesofthefirebox.Theyare
located behind the side panels. The side
panels do not need to be removed when
inserting the handles. Please refer to the
diagrambelow.
*cutawayview
shownforclarity
DecorativeRods
-Mahoganyonly
TheSaxonMahoganyhas4decorativerods
located in the top panel. These can be
removedsotheymaybepaintedanalternative
colour,ifdesired.
Toremovetherods,unscrewtheairslideknob
ontheleftsideoftheheater.Totakethetop
panelofftheheater,remove4screwsatthe
rear and one screwon each side ofthe top
panel, as show in diagram above. The top
panelneedstobeliftedslightlyverticalandto
thelefttocleartheairsliderod.
Placethetoppanelupsidedownonaclean,
softsurface.Eachrodhasonescrewholding
itinplace.Removeeachscrewsothatthe
rodcanberemoved.
Top
panel
screw
tabupwards
1
2
