INSTALLATION-GENERALNOTES
BeforeBeginning
Beforebeginningtheinstallationofyourwood
heater, you should note the following
precautions:
* WARNING:THEAPPLIANCEANDFLUE-
SYSTEM SHALL BE INSTALLED IN
ACCORDANCEWITHAS/NZS2918AND
THE APPROPRIATE REQUIREMENTS
OF THE RELEVANT BUILDING CODE
ORCODES.
* WARNING:APPLIANCESINSTALLEDIN
ACCORDANCEWITHTHISSTANDARD
S H A L L  C O M P L Y  W I T H  T H E
REQUIREMENTS OF AS/NZS 4013
W H E R E  R E Q U I R E D  B Y  T H E
REGULATORY AUTHORITY I.E. THE
APPLIANCE SHALL BE IDENTIFIABLE
BY A COMPLIANCE PLATE WITH THE
MARKINGTESTEDTOAS/NZS4013.
* WARNING:ANYMODIFICATIONOFTHE
APPLIANCE THAT HAS NOT BEEN
APP ROV ED IN WRI TIN G BY TH E
TESTINGAUTHORITYISCONSIDERED
TOBEINBREACHOFTHEAPPROVAL
GRANTED FOR COMPLIANCE WITH
AS/NZS4013.
* CAUTION: CRACKED AND BROKEN
COMPONENTS,e.g.GLASSPANELSOR
CERAMIC TILES, MAY RENDER THE
INSTALLATIONUNSAFE.
* It is strongly recommended that a
certified/qualified installer perform the
installation.
* Youmayneedtogetcouncilapprovalprior
toinstallation.
* Youshouldalsocheckwithyourinsurerfor
anyrequirementstheymayhave.
HearthRequirements
Ifyourwoodheateristobeinstalledoncarpet,
timberoranyothercombustiblematerial,you
must place a hearth (also known as a floor
protector) underneath the heater. Please
observethefollowing:
* Thehearthmustconsistofatleast12mm
ofnoncombustiblematerial
* Itisnotrecommendedthatyoumake
yourownhearth
* Thehearthandheaterassembly
mustbeplacedonafirmand
levelsurface.
FlueInstallation
For detailed instructions regarding flue
installation,seetheinstructionsthatcamewith
yourfluekit.
The correct flue system is critical to the
performance of your wood heater. It must
eitherbetestedwiththeheaterorbeadefault
fluekit.WerecommendyouuseaMaxiheat
DefaultFlueKit.
CAUTION: MIXING OF APPLIANCE OR
FLUE-SYSTEM COMPONENTS FROM
DIFFERENT SOURCES OR MODIFYING
THE DIMENSIONAL SPECIFICATION OF
C O M P O N E N T S  M A Y  R E S U L T  I N
HAZARDOUSCONDITIONS.WHERESUCH
A C T I O N  I S  C O N S I D E R E D ,  T H E
M A N U F A C T U R E R  S H O U L D  B E
CONSULTEDINTHEFIRSTINSTANCE.
FlueHeightRequirements
Your flue must extend the required height
aboveyourrooftopromotesufficientdraught.
Iftheflueisnothighenough,theheaterwillnot
draw properly causing smoke to spill back
intotheroom.
Theminimumheightoftheactivefluemustbe
4.6minlengthmeasuredfromthehearthplate
to the flue termination point. The flue must
extend at least 1m out of the roof. The flue
mustclearanyridgeorobstructionwithina3m
radiusbyaminimumof1m.
Forverysteeproofs(45°orsteeper)itisoften
impracticaltogetabovethehighestpoint.The
useofananti-downdraftcowlisadvisable.
Onflatroofs,thefluemustextendaminimum
of1.5m.
There are other variables that can affect
draught(eg treesor tallbuildingsnearby). If
youhavethecorrectflueheightandstillhave
problems,consultyourdealer.
