SBE SB-34 - Page 69

Q9 - Q10
Q7 - Q8
CR-9
CR-9
80 Meters
Receive
HF Crystal
HF Mixer
VFO
VFO Mixer
IF Crystal
IF Crystal
IF Mixer
IF Crystal
IF Mixer
Frequency
Frequency
Output
Frequency
Output
Frequency
Freq X 4
Output
Freq X 6
Output
3775 7200 3425 5706.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
3800 7200 3400 5681.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
3825 7200 3375 5656.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
3850 7200 3350 5631.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
3875 7200 3325 5606.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
3900 7200 3300 5581.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
3925 7200 3275 5556.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
3950 7200 3250 5531.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
3975 7200 3225 5506.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
4000 7200 3200 5481.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
4025 7200 3175 5456.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
40 Meters
Receive
HF Crystal
HF Mixer
VFO
VFO Mixer
IF Crystal
IF Crystal
IF Mixer
IF Crystal
IF Mixer
Frequency
Frequency
Output
Frequency
Output
Frequency
Freq X 4
Output
Freq X 6
Output
7050 10475 3425 5706.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
7075 10475 3400 5681.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
7100 10475 3375 5656.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
7125 10475 3350 5631.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
7150 10475 3325 5606.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
7175 10475 3300 5581.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
7200 10475 3275 5556.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
7225 10475 3250 5531.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
7250 10475 3225 5506.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
7275 10475 3200 5481.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
7300 10475 3175 5456.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
20 Meters
Receive
HF Crystal
HF Mixer
VFO
VFO Mixer
IF Crystal
IF Crystal
IF Mixer
IF Crystal
IF Mixer
Frequency
Frequency
Output
Frequency
Output
Frequency
Freq X 4
Output
Freq X 6
Output
14100 17525 3425 5706.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
14125 17525 3400 5681.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
14150 17525 3375 5656.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
14175 17525 3350 5631.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
14200 17525 3325 5606.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
14225 17525 3300 5581.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
14250 17525 3275 5556.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
14275 17525 3250 5531.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
14300 17525 3225 5506.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
14325 17525 3200 5481.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
14350 17525 3175 5456.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
15 Meters
Receive
HF Crystal
HF Mixer
VFO
VFO Mixer
IF Crystal
IF Crystal
IF Mixer
IF Crystal
IF Mixer
Frequency
Frequency
Output
Frequency
Output
Frequency
Freq X 4
Output
Freq X 6
Output
21200 24625 3425 5706.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
21225 24625 3400 5681.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
21250 24625 3375 5656.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
21275 24625 3350 5631.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
21300 24625 3325 5606.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
21325 24625 3300 5581.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
21350 24625 3275 5556.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
21375 24625 3250 5531.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
21400 24625 3225 5506.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
21425 24625 3200 5481.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
21450 24625 3175 5456.9 2281.9 456.38 1825.52 456.38 2738.28 456.38
Lower Sideband
Upper Sideband
Lower Sideband
Upper Sideband
Lower Sideband
Upper Sideband
Lower Sideband
Upper Sideband
