5
1. Bypass 7. Water Outlet
2. Valve Housing 8. Blending Regulator
3. Resin Vessel 9. Water Hardness Regulator
4. Salt Chamber 10. To Brine Float
5. Brine Float 11. Discharge to Drain
6. Water Inlet 12. Overflow
1
2
3
4
6
7
8
9
12
10
10
11
PLEASE NOTE
While the outward appearance
of the 150, 150C & 450 are
different the look of the
component parts will look
similar or the same as
described on this page.
