SCALEO infinity - Operation

4
COMMISSIONING
OPERATION
You will already nd the lamp completely assembled. To put the lamp into operation it is necessary to install
a battery that corresponds to the technical specications in terms of current and voltage. Depending on the
conguration, you can connect the SCALEO infinity with the E/O-Cord or permanently with a battery pack.
Alternatively, the Scaleo can also be operated with the compact slip battery pack. More information can be
found in the separate operating manual.
All common battery tanks are allowed to use if:
• they have an output voltage range between 8 V and 17V DC
• that have a battery management system
• their discharge current is rated for at least 9 ampere.
We recommend battery tanks from UwaVis.
1. ADAPTING THE LIGHT INTENSITY
You can regulate the light intensity of the spot and wide angle by using the rotary-switch Infinite Flux Control
(IFC). Both light cones can be infinitely dimmed continuously from 0 - 100 % of the intensity and are indepen-
dently combinable depending on the software variant.
There are two software variants for controlling the lamp: standard and cave software. If you press the button
for 8 seconds during on state the lamp switches between standard- and cave-software.
A: Standard-software:
Spot Click one time on the IFC button to release the key lock and activate the spot mode. Then
turn the IFC knob clockwise to increase the light intensity of the spotlight or coun-
terclockwise to decrease it.
Wide angle Click two times quickly on the IFC button to release the key lock and to activate the wide
angle mode. Then turn the IFC knob clockwise or counterclockwise to regulate the light
intensity of the wide angle.
Key lock After 3 seconds of inactivity the key lock will be activated automatically. If you turn the IFC
knob without clicking the IFC button before, the key lock mode will remain activated. In this
mode the light intensity can not be regulated and the control lights will show the battery
status.
