Using the Transport Fitting
See separate instructions for use on transport fitting.
Mounting of the Accessories
Mounting of siderail
The siderail may be mounted with the release system at the head or foot end of the
bed.
!
Note: however, that on the extra-long bed the release system MUST be at the
head of the bed.
The fork links on the siderail are placed over the black-striped fields on the side tube.
Tighten the siderail with two thumb screws.
!
Risk of squeezing fingers on assembly and operation of the siderails.
Mounting the Lifting Pole
Remove the plug from the lifting pole tube at the head end of the bed where the lifting
pole is to be placed.
Insert the lifting pole into the lifting pole tube and fix with the thumb screw.
Mounting of Mattress Handle on Leg Section.
Press the mattress handle down over the tube frame on the leg section.
Check by examining its position on the backrest.
