Handle
The handle is elegantly integrated on the moulding below the
door. Pull out the handle to open.
Adjustment of the handle
Loosen the screw in the adjustment bushing (1) with a
hexagon spanner. Adjust the handle to the moulding with the
adjustment bushing and tighten the screw again.
Accessories
For this model you can have the following accessories:
Adjustment screws
The stove has two adjustment screws on the bottom that can
be used for levelling the stove.
Self-closing door (BA 1)
The door is prepared with a self-closing function at the fac-
tory. If you tighten the spring with the hexagon spanner, the
door will close automatically when you let go of it.
• Lateral covering in soapstone or stainless steel
• Glazed baking tile
• Soapstone-top plate
• Shaped floor plate (steel or glass)
• Connection piece for fresh-air intake
You should read this manual as well as the General Instructions for Installation before beginning the installation.
SCAN 39
1
The stove can be prepared for an external air supply where
fresh air is let directly into the combustion chamber (can also
be done subsequently by the authorized dealer).
Combustion air % Primary air % Max. fuel, kg Fuel consumption, kg/h
90 60 2 2
Adjustment of the air + fuel consumption (EN 13240):
