ASSEMBLY
5
Load bearing underlay
All of the products in our portfolio are classified as light-duty fire-
places; in most cases, there is no need to reinforce the floor, so that
you can typically use the normal floor.
However, you should make sure that the load bearing underlay
can bear the weight of the wood-burning stove and that of the
chimney.
Floor plate
If you are setting up the stove on a flammable floor, observe natio-
nal and local regulations on the size of the non-flammable underlay
that covers the floor around the stove.
Your local Scan dealer can advise you on regulations concerning
flammable materials in the vicinity of your stove.
The idea behind the floor plate is that it protects the floor and flam-
mable material against sparks.
The floor plate can be made of steel or glass, and the stove can be set
up on brick, natural stone or similar materials.
This Scan wood-burning stove has an integrated floor plate, and
can thus be set up on any flammable material without a protective
underlay.
If you are using a shaped floor plate, you should adjust the stove
upwards to allow the plate to be inserted under the front of the
stove.
Type plate
All Scan wood-burning stoves are fitted with a type plate, that
specifies the approval standards and the distance to flammable
materials.
Scan 53
Freestandin
Unpacking
We recommend that you leave the protective film on the stove until
fitting is complete.
Service package
The service package contains the following:
• Fitting for flue collar
• Seal for flue collar
• Safety fitting
• Plastic plugs for transport safety hole at the bottom of the
stove
• Various tools
• Glove
• Fire starters for first lighting
Accessories
• Shaped floor plate in steel or glass
• Glass top plate
• Front shelf in glass, steel or stainless steel
• Fresh-air box, external combustion air
• Fresh-air connection piece
