ASSEMBLY
9
Remove the cover plate at the rear of the stove.
6 x Allen screws M4x6
The cover plate in the bottom of the stove is dismounted.
A
A
Loosen the screws in the stove. Mount
the fresh air box. Tighten the screws
again.
Fresh air box
Outside air for combustion is supplied through the wall. Outside air for combustion is supplied through the fl oor.
Fitting the fresh air box
Fit the connection piece and blanking plate.Fit the blanking plate. Fasten the connection piece after the fresh air
box has been fi tted, as the location may vary from stove to stove.
6 x Allen screws M4x6
