Pairing procedure for HANDY radio remote control
1) Get started with the receiver and the transmitter both off.
2) Remove the protective cap and screw on the connector the
special yellow plug supplied with the remote control
(Pairing Plug p/n: 48118).
3) Switch on the transmitter in ASSIGN
mode: holding down the keys 3 and
4, press and release the STOP button.
"A" will appear on the display.
4) Switch on the receiver in REMOTE mode (the transmitter must be switched on in ASSIGN
mode and near the receiver: distance less than 15
cm).
5) Wait about 30 seconds.
6) Turn off the transmitter.
7) Turn off the receiver.
8) Unscrew the yellow plug (PAIRING PLUG) and put it in a safe place for future use.
9) Install again the protection cap on the receiver connector.
On the next system restart the receiver will recognize the transmitter and will operate normally
("1H" is written in the receiver internal display and the status LED is turned on green).
Repeat the procedure from the beginning if the transmitter was not recognized.
