SCHABMULLER TSA Series - Mounting incremental encoder on counterpart

Operating and maintenance instructions
Installing optional attachments
Version 1.0 Page 32 of 56
Proceed in the order given:
Step
Procedure
1
Remove the cap.
2
Push the incremental encoder (item 1) onto the shaft.
3
Insert the cylinder pin (item 2) correctly into the rubber part; maintain an
air gap of min. 0.9 mm and max. 1.0 mm between the incremental
encoder and flange.
4
Mount the fastening elements with the cylinder screw (item 3) with screw
lock medium tight (e.g. Three Bond 1344) and with a tightening torque of
1 Nm.
