Schaudt AD 01 - AD 03 Adapter Layout; Maintenance

Installation instructions for adapter AD 01...03
8
Date: 01.08.2012 822.371 BA / EN
5.3 AD 03
B4
B1
B2
B6
B3
B5
B8
B7
1121110923 45 78 13
14
156
16
Fig. 4 AD 03 adapter
1 B3: Connector, output terms. 15 & 30
2 B8: Position light, low-beam light, output terms. 15 & 30
3 B7: Position light
4 B6: Position light
5 B4: Connector, term. 15
6 B5: 12V when engine is running (D+)
7 B2: Connector, vehicle control voltages (D+, term. 15, low-beam light
and position lights)
8 Fuse B12: Flat vehicle fuse
9 Fuse B14: Flat vehicle fuse
10 Fuse B13: Flat vehicle fuse
11 Fuse B11: Flat vehicle fuse
12 B1: Connector, vehicle battery
13 Casing
14 Adhesive label
15 Switchover, position lights active +12V/GND
16 Switchover D+ active +12V/GND
6 Maintenance
The adapters do not require maintenance.
