4 Situation: 25.11.2009 805.031 BA / EN
Instruction Manual Power Supply Unit CSV 300
The power supply unit is designed for use in caravans with no living area bat-
tery of their own and can therefore not be used for charging batteries.
Fig. 1 Power supply unit CSV 300, CSV 300 2B10, CSV 300 2B13
and CSV 300-3
1 Negative 12 V outputs, circuits 1 to 5
2 + 12 V outputs, circuits 1 to 5
3 + 12 V Car battery/tow bar
4 + 12 V Car battery/tow bar
5 Flat vehicle fuses
6 Fuse puller
7 Spaces for circuit breakers
3 $4



.)=
$79 +]
$ 7%
0LQXV .UHLV .)=
 .UHLV 

