SDT-0054-00EN Situation: 15.06.2005 5
Instruction Manual Electrobloc EBL 99 G
6 Operation
6.1 Operating controls
Flat vehicle fuses
The flat vehicle fuses protect the various circuits.
Battery cut-off switch The battery cut-off switch "Batterie Ein/Aus" (battery on/off) disconnects the
following connections from the living area battery:
P
All 12 V consumers
P
The frost protection valve
P
The control and switch panel
This prevents the living area battery from slowly discharging due to closed cir-
cuit current while the vehicle is not in use.
The batteries can still be charged using the Electrobloc, the alternator, an
auxiliary charging unit or the solar charge regulator, even when the battery
cut-off switch is switched off.
Start up the system
Set the battery cut-off switch on the Electrobloc to "Batterie Ein" (battery
on).
After switching on the battery cut-off switch or after changing batteries:
Switch on the 12 V main switch on the control and switch panel briefly to
start up the consumers.
Shutting down the system
Set the battery cut-off switch to "Batterie Aus" (battery off).
W
Blown fuses must only be replaced when the cause of the fault is
known and eliminated.
W
Never bridge or repair fuses.
W
Danger of burning! Blown fuses must only be changed on a zero-cur-
rent Electrobloc.
W
Only use original fuses rated as specified in the instruction manual.
W
Before starting up:
P
Make sure the living area battery is connected.
P
Make sure the battery selector switch is set for the correct type of bat-
tery.
P
Make sure the AES fuse is only used if the AES refrigerator is connect-
ed. Otherwise, the living area battery may get totally discharged. Bat-
tery damage is possible.
W
When the living area battery is separated from the Electrobloc by the bat-
tery cut-off switch, the frost protection valve of the heater system opens.
Water may be lost. For more information, see the instruction manual of the
heater system.
