Instruction Manual for Electroblock EBL 252
7
Date: 23.01.2020
8110253 BA / EN
5 Functions
5.1 Battery charge functions
Simultaneous charging of the starter battery and the leisure battery by the alternator, parallel
connection of the batteries via a cut-off relay.
There is also simultaneous charging of the starter battery and leisure battery (up to 18A in
total) for a connection to the 230V supply. The switch ensures optimal charging of the lead-
acid and AGM battery types.
If a solar regulator is connected to the EBL 252, together with a solar panel, the two batte-
ries are charged automatically given sufficient sunshine.
5.2 Additional functions
This relay supplies the AES/compressor refrigerator with power from the starter battery
when the vehicle engine is running and the D+ connection is live. An AES refrigerator is also
powered by the leisure battery when the vehicle engine is not running.
CAUTION!
The ”AES / Compressor refrigerator” fuse (see Fig. 2, Pos. 11) may only be used when the
refrigerator installed in the vehicle is a compressor refrigerator. If it is deployed when using
an absorber refrigerator, the leisure battery is discharged within a short period.
The power supply of this consumer is interrupted automatically as soon as the engine is run-
ning. The awning light can still be used even if the 12V supply is switched off.
The power supply of this consumer is automatically switched on as soon as the engine is
running. Provided the engine is running, this means an additional electric heater can be ope-
rated for the vehicle. The output is enabled instead of the output for the awning light, and
hence has common fusing together with the awning light.
The power supply for the water pump is switched on and off by a switching stage in the
EBL 252 electroblock via the operator and control panel connected.
6Faults
A flat battery or defective fuse is the cause of most f aults in the 12V system.
When it is not possible to rectify a fault based on the following table, please contact Schaudt
customer service (for address, see Page 11).
The following signals are protected by a resettable fuse (polyswitch):
F 12V indicator
F Battery 1 sensor (starter battery) on operator and control panel, see block diagram on
Page 12
F Output D+
Fault Possible cause Remedy
L
eisure batter
y
is not char
g
ed No mains volta
g
e Switch on the automatic circuit
L
e
i
s
u
r
e
b
a
t
t
e
r
y
i
s
n
o
t
c
h
a
r
g
e
d
during 230V operation (battery
N
o
m
a
i
n
s
v
o
l
t
a
g
e
S
w
i
t
c
h
o
n
t
h
e
a
u
t
o
m
a
t
i
c
c
i
r
c
u
i
t
breaker in the vehicle; check the
g
p
(
y
voltage permanently below
1
3
3
V
)
;
mains voltage
13.3 V)
Too many consumers are swit-
ched on
Switch off any consumers not
required
Defective electroblock Contact customer service
Leisure battery is overcharged
during 230V operation (battery
voltage constantly above
14.5 V)
Defective electroblock Isolate the device from the 230V
mains s upply and contact custo-
mer service
Charging
whilst on the
move
Mains
charging
Charging
with
solar panel
AES/
compressor
refrigerator
Awning light
Additional
50W heater
Water pump
Flat vehicle
fuses
Polyswitch
fuses
